Inlet: 1

Outlet: 1

Capacity: 5.0~50cc/rev

Working Pressure: ≤25Mpa

Working Temperature: ≤330℃ (Customizable for higher temperatures)
The temperature depends on the sealing ring material and pump body material

Rotational Speed: 5-40r/min
It should be used with reduced speed and pressure for high viscosity or non lubricating fluids

Main applications: Spinning of nylon, Polypropylene, Polyester, Carbon fiber, etc
(Special media require replacement of pump body materials)
